Description
ABSIMA 1:10 Brushed WP 40A ESC 2-3S – AB2100004
PLEASE NOTE: Tamiya plug can be changed instore, whilst you wait, by request.
We proudly present our new programmable “ALL-IN-ONE” BRUSHED SPEED CONTROLLER which can be used for 1:10 RC Crawlers and also Race Cars. The basic setting for the vehicle and battery type is done via “jumpers” on the ESC. In addition, a programming card is available, which can be used for even more settings.
HIGHLIGHTS:
One ESC for all vehicle types (Crawler, Off-road, On-road, Boat).
Programmable via jumper and separately available programming card (Item: 2110061)
2-3S LiPo capable
Continuous load: 80A
BEC: 5A / 6.0V
Programmable Features (via programming card):
Initial Start Force: 5%* / 13% / 21% / 29%
Low V cut-off: 3.1V* / 3.4V / Off
Crawler Setup – Initial Drag Brake: 100%* / 90% / 80% / 70%
Standard Setup – Max Brake Force: 50%* / 100% / 75% / 25%
Max Reverse Force: 50%* / 75% / 100%
Start Mode (Punch): Medium* / Strong / Soft
